2024 Kawasaki KX112 at Jean Dumas Maximum Sport

Standard

• Final Drive - Chain
• Transmission - 6-speed, return
• Ignition - Digital-CDI
• Starting - Primary kick
• Lubrication - Pre-mix (32:1)
• Fuel System - Carburettor: Keihin PWK28
• Engine - 112cc, liquid-cooled, 2-stroke single with KIPS
• Bore x Stroke - 52.5 x 51.6 mm
• Clutch: Wet multi-disc, manual
• Induction: Piston reed valve
• Compression Ratio - 9.9:1 (low speed), 8.6:1 (high speed)

Standard

• Wheelbase - 1,310 mm (51.6 in)
• Seat Height - 870 mm (34.3 in)
• Fuel Capacity - 5.0 litres
• Dimensions (L x W x H) - 1,920 x 765 x 1,150 mm (75.6 x 30.1 x 45.3 in)
• Road Clearance - 330 mm (13.0 in)
• Curb Mass - 77.0 kg (170 lb)
• Mass Without Fuel: 73.3 kg (162 lb)

Standard

• Steering Angle (L/R) - 45° / 45°
• Front Tire - 70/100-19 42M
• Frame - Perimeter, high-tensile steel
• Front Suspension / Wheel Travel - ø36 mm inverted fork with adjustable compression damping / 275 mm (10.8 in)
• Rear Suspension / Wheel Travel - Uni Trak with adjustable compression and rebound damping and adjustable spring preload / 275 mm (10.8 in)
• Front Brake: ø220 mm petal disc with dual-piston caliper
• Rear Brake: ø184 mm petal disc with single-piston caliper
• Rake / Trail - 29.0° / 108 mm
• Rear Tire - 90/100-16 51M
